High Capacity Load Cell DPU
High Capacity Load Cell DPU

High Capacity Load Cell DPU

Price 30000.0 INR/ Number

MOQ : 1 Number

High Capacity Load Cell DPU Specification

  • Humidity %
  • 95% RH (non-condensing)
  • Capacity
  • 50 Ton to 300 Ton
  • Diameter
  • As per capacity; generally 80 mm to 150 mm
  • Sensor Type
  • Strain Gauge
  • Measurement Range
  • Customized as per model (e.g., 0-200 Ton)
  • Temperature Range
  • -10C to +70C
  • Connectivity Type
  • 4-wire shielded cable
  • Resolution
  • 1/10,000
  • Protection
  • IP67
  • Equipment Type
  • High Capacity Load Cell (DPU Type)
  • Frequency
  • DC; Not Applicable
  • Application Media
  • Solid loads, compression applications
  • Usage
  • Industrial
  • Material
  • Alloy Steel
  • Power Supply
  • 10 V DC nominal (recommended)
  • Product Type
  • High Capacity Load Cell DPU
  • Power Consumption
  • Low
  • Accuracy
  • 0.05% of rated output
  • Weight
  • 500 Grams (g)
  • Display Type
  • No integrated display (external indicator required)
  • Color
  • Black
  • Range
  • Up to 50, 100, 200, 300 Ton options
  • Insulation Resistance
  • >= 5000 MOhms (50V DC)
  • Creep (30 minutes)
  • 0.03% of rated output
  • Safe Overload
  • 150% of rated capacity
  • Input Resistance
  • 770 10 Ohms
  • Output Sensitivity
  • 2.0 mV/V nominal
  • Excitation Voltage
  • 5V to 12V DC
  • Cable Length
  • 10 m (standard)
  • Output Resistance
  • 700 5 Ohms
  • Sealing
  • Hermetically sealed
  • Mounting
  • Base Mounting
  • Ultimate Overload
  • 200% of rated capacity


High Capacity Load Cell DPU Trade Information

  • Minimum Order Quantity
  • 1 Number
  • Supply Ability
  • 100 Per Week
  • Delivery Time
  • 1 Week


About High Capacity Load Cell DPU

Brand Imada
Shape Rectangular
Design Dynamic
Usage/Application Industrial
Material Alloy Steel


Capacity

1000N- 20kN

Accuracy

-/+ 0.2 % F.S or less

Size

App. W58xD26xH30 - W88xD42xH55mm

Cable Length

Approx 3m



Precision and Durability for Heavy-Duty Applications

The High Capacity Load Cell DPU is engineered for environments that demand strength and accuracy. Its alloy steel construction and hermetic sealing (IP67) ensure it withstands harsh industrial conditions, while the advanced strain gauge technology delivers a resolution of 1/10,000 and exceptional repeatability. Specifically suited for compression and solid load applications, this load cell adapts to a broad measurement range, customized per project requirements.


Flexible Connectivity and Ease of Integration

Designed for seamless integration, the DPU-type load cell features a 4-wire shielded cable with a standard length of 10 meters, allowing for flexible installation in diverse setups. It operates with most standard external digital indicators (since it requires an external display) and maintains stable output with an excitation voltage between 5V and 12V DC. Its base mounting further simplifies the installation process for industrial clients.

FAQ's of High Capacity Load Cell DPU:


Q: How is the High Capacity Load Cell DPU typically used in industrial applications?

A: The DPU load cell is primarily used for measuring compression forces in heavy-duty industrial scenarios, such as weighing silos, hoppers, or heavy machinery. Its high accuracy and robust design make it suitable for solid load measurements where reliability and precision are crucial.

Q: What is the installation process for this load cell?

A: Installation involves base-mounting the load cell securely at the desired measurement point, connecting the 4-wire shielded cable to a compatible external indicator, and ensuring proper power supply (nominally 10V DC). Its long cable and standardized interface simplify setup in various industrial layouts.

Q: When should I opt for this load cell over standard models?

A: Choose the DPU load cell when you require higher load capacity (up to 300 tons), superior accuracy (0.05% of rated output), and better environmental protection (IP67 hermetic sealing), especially in challenging or high-moisture environments.

Q: Where can I use the DPU load cell within an industrial setting?

A: This load cell is well-suited for any setting that demands reliable compression measurement, such as production lines, storage facilities, or testing laboratories across several industries in India. Its IP67 rating allows use even where moisture or dust is present.

Q: What are the benefits of hermetic sealing and IP67 protection?

A: Hermetic sealing and IP67 protection safeguard the load cell's internal components against dust, moisture, and other contaminants, ensuring long-term durability and consistent performance, even in harsh or outdoor environments.

Q: How accurate are the readings and what is the device's resolution?

A: The load cell delivers high-precision measurements with an accuracy of 0.05% of rated output and a resolution of 1/10,000, ensuring dependable results for critical industrial weighing applications.
